Appendix B Setpoint Actions
SA300 Substation Automation Unit 159
Appendix B Setpoint Actions
Action Target Description
NONE None (no action)
SET EVENT FLAG 1-16 Set user event flag 1-16
CLEAR EVENT FLAG 1-16 Clear user event flag 1-16
OPERATE RELAY 1-32 Operate relay RO1-RO32
RELEASE RELAY 1-32 Release latched relay RO1-RO32
INCREMENT COUNTER 1-32 Increment counter 1-32
DECREMENT COUNTER 1-32 Decrement counter 1-32
CLEAR COUNTER 1-32 Clear counter 1-32
RESET ENERGY Reset total energy registers
RESET DEMANDS ALL Reset all maximum demand registers
RESET DEMANDS POWER Reset maximum power demand registers
RESET DEMANDS VOLT/AMP Reset maximum volts and ampere demand registers
RESET DEMANDS VOLT Reset maximum volt demand registers
RESET DEMANDS AMP Reset maximum ampere demand registers
RESET DEMANDS HRM Reset maximum harmonic demand registers
RESET TOU ENERGY Reset summary and TOU energy
RESET TOU DEMANDS Reset summary and TOU maximum demands
RESET ALL COUNTERS Clear all counters
CLEAR MIN/MAX LOG Clear Min/Max log registers
EVENT LOG OPER Event log on setpoint operated
EVENT LOG RELS Event log on setpoint released
EVENT LOG ANY Event log on any setpoint transition
DATA LOG 1-16 Data log 1-16
WAVEFORM LOG 1-8 Waveform Log 1-8
SOE LOG SOE (Sequence of Events) Log
EXT TRIGGER 1-16 External trigger 1-16 (UDP broadcast trigger message).
See
Cross Triggering Setpoints .
