Appendix C Parameters for Monitoring and Data Logging
SA300 Substation Automation Unit 173
Designation Description
MAX DMD Maximum Demands
V1 DMD MAX V1/V12 Maximum volt demand 1
V2 DMD MAX V2/V23 Maximum volt demand 1
V3 DMD MAX V3/V31 Maximum volt demand 1
I1 DMD MAX I1 Maximum ampere demand
I2 DMD MAX I2 Maximum ampere demand
I3 DMD MAX I3 Maximum ampere demand
kW IMP SD MAX Maximum kW import sliding window demand
kvar IMP SD MAX Maximum kvar import sliding window demand
kVA IMP SD MAX Maximum kVA sliding window demand
kvar IMP SD MAX Maximum kW export sliding window demand
kvar EXP SD MAX Maximum kvar export sliding window demand
V4 DMD MAX V4 Maximum volt demand
I4 DMD MAX I4 Maximum ampere demand
In DMD MAX In Maximum ampere demand
MAX HRM DMD Maximum Harmonic Demands
V1 THD DMD MAX V1/V12 THD demand 1
V2 THD DMD MAX V2/V23 THD demand 1
V3 THD DMD MAX V3/V31 THD demand 1
V4 THD DMD MAX V4 THD demand
I1 THD DMD MAX I1 THD demand
I2 THD DMD MAX I2 THD demand
I3 THD DMD MAX I3 THD demand
I4 THD DMD MAX I4 THD demand
I1 TDD DMD MAX I1 TDD demand
I2 TDD DMD MAX I2 TDD demand
I3 TDD DMD MAX I3 TDD demand
I4 TDD DMD MAX I4 TDD demand
MAX SUMMARY DMD Maximum Summary (TOU Total) Demands
SUM REG1 DMD MAX Summary register #1 maximum demand
SUM REG2 DMD MAX Summary register #2 maximum demand
… …
SUM REG16 DMD MAX
Summary register #16 maximum demand
MAX PRG Programmable Min/Max Maximum Registers
PROG REG1 MAX Min/Max Register #1
PROG REG1 MAX Min/Max Register #2
… …
PROG REG16 MAX
Min/Max Register #16
ANALOG INPUTS Scaled Analog Inputs (Engineering Units)
AI1 Analog input AI1
AI2 Analog input AI2
…
AI16
Analog input AI16
AI RAW Raw Analog Inputs (A/D Units)
AI1 RAW Analog input AI1
AI2 RAW Analog input AI2
…
AI16 RAW
Analog input AI16
AO RAW Raw Analog Outputs (A/D Units)
AO1 Analog output AO1
AO2 Analog output AO2
…
AO16
Analog output AO16
TOU PRMS TOU Parameters
ACTIVE TARIFF Active TOU tariff
ACTIVE PROFILE Active TOU profile
TOU REG1 TOU Energy Register #1
TOU REG1 TRF1 Tariff #1 register
TOU REG1 TRF2 Tariff #2 register
… …
TOU REG1 TRF16
Tariff #16 register
TOU REG2 TOU Energy Register #2
TOU REG2 TRF1 Tariff #1 register
TOU REG2 TRF2 Tariff #2 register
… …
