Appendix C Parameters for Monitoring and Data Logging
160 SA300 Substation Automation Unit
Appendix C Parameters for Monitoring and Data
Logging
The following table lists parameters measured by the SA300 that are available for
monitoring via communication ports, for data logging, and for triggering setpoints.
Designation Description
NONE None (stub, read as zero)
SETPOINTS Setpoint Status
SP1:32 Setpoints 1-32
SPECIAL INPUTS Special Inputs (setpoint triggers only)
VOLT DISTURB Voltage disturbance – waveshape fault. See Using the Voltage
Disturbance Trigger .
PHASE ROTATION Phase rotation order
EVENT FLAGS User Event Flags
EVENT FLAG 1:16 Event Flags 1-16
STATIC EVENTS Internal Static Events (setpoint triggers only)
PHASE ORDER ERR Phase order error
POS PHASE ORDER Positive (ABC) phase order
NEG PHASE ORDER Negative (ACB) phase order
PQ EVENT PQ event. See Power Quality Event Indication and Cross Triggering .
FAULT EVENT General fault event: fault recorder has been triggered. See Fault
Indication and Cross Triggering .
FAULT DETECTED The embedded fault detector has detected a fault. See Fault Indication
and Cross Triggering .
EXTERNAL TRIGGER Fault recorder has been triggered via a digital input. See Fault
Indication and Cross Triggering .
DEVICE FAULT Device fault (non-critical error). See Device Fault Alarm .
NO VOLTAGE No measured voltage
PULSED EVENTS Internal Pulsed Events (setpoint triggers only)
kWh IMP PULSE kWh Import pulse
kWh EXP PULSE kWh Export pulse
kWh TOT PULSE kWh Total pulse
kvarh IMP PULSE kvarh Import pulse
kvarh EXP PULSE kvarh Export pulse
kvarh TOT PULSE kvarh Total pulse
kVAh PULSE kVAh pulse
START DMD INT Start of power demand interval pulse
START TRF INT Start of tariff interval pulse
EXT TRIGGERS External Trigger Events (setpoint triggers only)
EXT TRIGGER 1:16 External cross triggering channel 1-16 (UDP broadcast trigger message).
See
Cross Triggering Setpoints .
TIMERS Interval Timers (setpoint triggers only)
TIMER 1:16 Interval timer 1-16
DIGITAL INPUTS Digital Inputs
DI1:48 Digital input status DI1:DI48
PULSE INPUTS Pulse Inputs (setpoint triggers only)
DI1:48 Transition pulse on a digital input DI1:DI48
RELAYS Relays
RO1:16
Relay status RO1:RO2
COUNTERS Pulse Counters
COUNTER 1:32 Pulse counter 1-32
TIME Time/Date Parameters (setpoint triggers only)
DATE Date (DDMMYY)
TIME Time (HHMMSS)
DAY OF WEEK Day of week
YEAR Year
MONTH Month
DAY OF MONTH
Day of month
HOURS Hours
MINUTES Minutes
SECONDS Seconds
SYMM COMP
Symmetrical Components
V PSEQ Positive-sequence voltage
