Appendix C Parameters for Monitoring and Data Logging
168 SA300 Substation Automation Unit
Designation Description
I3 Mag I3 Current magnitude
I4 Mag I4 Current magnitude
V1 Ang V1/V12 Voltage angle 1
V2 Ang V2/V23 Voltage angle 1
V3 Ang V3/V31 Voltage angle 1
V4 Ang V4 Voltage angle
I1 Ang I1 Current angle
I2 Ang I2 Current angle
I3 Ang I3 Current angle
I4 Ang I4 Current angle
I1x Mag I1x Current magnitude
I2x Mag I2x Current magnitude
I3x Mag I3x Current magnitude
I4x Mag I4x Current magnitude
I1x Ang I1x Current angle
I2x Ang I2x Current angle
I3x Ang I3x Current angle
I4x Ang I4x Current angle
DEMANDS Present Demands
V1 DMD V1/V12 Volt demand 1
V2 DMD V2/V23 Volt demand 1
V3 DMD V3/V31 Volt demand 1
I1 DMD I1 Ampere demand
I2 DMD I2 Ampere demand
I3 DMD I3 Ampere demand
kW IMP BD kW import block demand
kvar IMP BD kvar import block demand
kVA BD kVA block demand
kW IMP SD kW import sliding window demand
kvar IMP SD kvar import sliding window demand
kVA SD kVA sliding window demand
kW IMP ACC DMD kW import accumulated demand
kvar IMP ACC DMD kvar import accumulated demand
kVA ACC DMD kVA accumulated demand
kW IMP PRD DMD kW import predicted sliding window demand
kvar IMP PRD DMD kvar import predicted sliding window demand
kVA PRD DMD kVA predicted sliding window demand
PF IMP@kVA MXDMD PF (import) at Maximum kVA sliding window demand
kW EXP BD kW export block demand
kvar EXP BD kvar export block demand
kW EXP SD kW export sliding window demand
kvar EXP SD kvar export sliding window demand
kW EXP ACC DMD kW export accumulated demand
kvar EXP ACC DMD kvar export accumulated demand
kW EXP PRD DMD kW export predicted sliding window demand
kvar EXP PRD DMD kvar export predicted sliding window demand
V4 DMD V4 Volt demand
I4 DMD I4 Ampere demand
In DMD In Ampere demand
HRM DMD Present Harmonic Demands
V1 THD DMD V1/V12 THD demand 1
V2 THD DMD V2/V23 THD demand 1
V3 THD DMD V3/V31 THD demand 1
V4 THD DMD V4 THD demand
I1 THD DMD I1 THD demand
I2 THD DMD I2 THD demand
I3 THD DMD I3 THD demand
I4 THD DMD I4 THD demand
I1 TDD DMD I1 TDD demand
I2 TDD DMD I2 TDD demand
I3 TDD DMD I3 TDD demand
I4 TDD DMD I4 TDD demand
SUMM ACC DMD Summary (TOU Total) Accumulated Demands
SUM REG1 ACC DMD Summary register #1 demand
SUM REG2 ACC DMD Summary register #2 demand
