Appendix C Parameters for Monitoring and Data Logging
162 SA300 Substation Automation Unit
Designation Description
V23 V23 Voltage
V31 V31 Voltage
I1x I1x Current
I2x I2x Current
I3x I3x Current
RT LOW 1-Cycle Low Values on any Phase
V LOW Low L-N voltage
I LOW Low current
kW LOW Low kW
kvar LOW Low kvar
kVA LOW Low kVA
PF LAG LOW Low lagging PF
PF LEAD LOW Low leading PF
THD LOW Low voltage THD 1
V THD LOW Low current THD
KF LOW Low K-Factor
I TDD LOW Low current TDD
V L-L LOW Low L-L voltage
V THD/I LOW Low voltage interharmonics THD 1
I THD/I LOW Low current interharmonics THD
RT HIGH 1-Cycle High Values on any Phase
V HIGH High L-N voltage
I HIGH High current
kW HIGH High kW
kvar HIGH High kvar
kVA HIGH High kVA
PF LAG LOW High PF Lag
PF LEAD LOW High PF Lead
THD LOW High voltage THD 1
V THD LOW High current THD
KF LOW High K-Factor
I TDD LOW High current TDD
V L-L LOW High L-L voltage
V THD/I LOW High voltage interharmonics THD 1
I THD/I LOW High current interharmonics THD
RT TOTAL 1-Cycle Total Values
kW Total kW
kvar Total kvar
kVA Total kVA
PF Total PF
PF LAG Total PF lag
PF LEAD Total PF lead
kW IMP Total kW import
kW EXP Total kW export
kvar IMP Total kvar import
kvar EXP Total kvar export
V AVG 3-phase average L-N voltage
V LL AVG 3-phase average L-L voltage
I AVG 3-phase average current
RT AUX 1-Cycle Auxiliary Values
I4 I4 current
In In current
FREQ Frequency
V UNB%
Voltage unbalance
I UNB% Current unbalance
VDC DC voltage
V4 V4 voltage
I4x I4x current
AVR PHASE 1-Second Phase Values
V1 V1 Voltage
V2 V2 Voltage
V3 V3 Voltage
I1 I1 Current
I2 I2 Current
I3 I3 Current
