Appendix C Parameters for Monitoring and Data Logging
SA300 Substation Automation Unit 169
Designation Description
… …
SUM REG16 ACC DMD
Summary register #16 demand
SUMM BLK DMD Summary (TOU Total) Block Demands
SUM REG1 BLK DMD Summary register #1 demand
SUM REG2 BLK DMD Summary register #2 demand
… …
SUM REG16 BLK DMD
Summary register #16 demand
SUMM SW DMD Summary (TOU Total) Sliding Demands
SUM REG1 SW DMD Summary register #1 demand
SUM REG2 SW DMD Summary register #2 demand
… …
SUM REG16 SW DMD
Summary register #16 demand
ENERGY Total Energy
kWh IMPORT kWh import
kWh EXPORT kWh export
kWh NET kWh net
kWh TOTAL kWh total
kvarh IMPORT kvarh import
kvarh EXPORT kvarh export
kvarh NET kvarh net
kvarh TOTAL kvarh total
kVAh TOTAL kVAh total
Vh Volt-hours
Ah Ampere-hours
SUMMARY REGS
Summary (TOU Total) Energy Registers
SUM REG1 Summary energy register #1
SUM REG2 Summary energy register #2
… …
SUM REG16
Summary energy register #16
%HD V1 V1/V12 Harmonic Distortions 1
V1 %HD01 H01 Harmonic distortion
V1 %HD02 H02 Harmonic distortion
… ...
V1 %HD63
H63 Harmonic distortion
%HD V2 V2/V23 Harmonic Distortions 1
V2 %HD01 H01 Harmonic distortion
V2 %HD02 H02 Harmonic distortion
… ...
V2 %HD63
H63 Harmonic distortion
%HD V3 V3/V31 Harmonic Distortions 1
V3 %HD01 H01 Harmonic distortion
V3 %HD02 H02 Harmonic distortion
… ...
V3 %HD63
H63 Harmonic distortion
%HD V3 V4 Harmonic Distortions
V3 %HD01 H01 Harmonic distortion
V3 %HD02 H02 Harmonic distortion
… ...
V3 %HD63
H63 Harmonic distortion
%HD I1 I1 Harmonic Distortions
I1 %HD01 H01 Harmonic distortion
I1 %HD02 H02 Harmonic distortion
… ...
I1 %HD63
H63 Harmonic distortion
%HD I2 I2 Harmonic Distortions
I2 %HD01 H01 Harmonic distortion
I2 %HD02 H02 Harmonic distortion
… ...
I2 %HD63
H63 Harmonic distortion
%HD I3 I3 Harmonic Distortions
I3 %HD01 H01 Harmonic distortion
I3 %HD02 H02 Harmonic distortion
… ...
I3 %HD63
H63 Harmonic distortion
%HD I4 I4 Harmonic Distortions
