Appendix C Parameters for Monitoring and Data Logging
170
SA300 Substation Automation Unit
Designation Description
I3 %HD01
H01 Harmonic distortion
I3 %HD02
H02 Harmonic distortion
… ...
I3 %HD63
H63 Harmonic distortion
HRM V1
V1/V12 Harmonic Voltages (odd harmonics)
1
V1 H01
H01 Harmonic voltage
V1 H03
H03 Harmonic voltage
… ...
V1 H63
H63 Harmonic voltage
HRM V2
V2/V23 Harmonic Voltages (odd harmonics)
1
V2 H01
H01 Harmonic voltage
V2 H03
H03 Harmonic voltage
… ...
V2 H63
H63 Harmonic voltage
HRM V3
V3/V31 Harmonic Voltages (odd harmonics)
1
V3 H01
H01 Harmonic voltage
V3 H03
H03 Harmonic voltage
… ...
V3 H63
H63 Harmonic voltage
HRM V4
V4 Harmonic Voltages (odd harmonics)
V4 H01
H01 Harmonic voltage
V4 H03
H03 Harmonic voltage
… ...
V4 H63
H63 Harmonic voltage
HRM I1
I1 Harmonic Currents (odd harmonics)
I1 H01
H01 Harmonic current
I1 H03
H03 Harmonic current
… ...
I1 H63
H63 Harmonic current
HRM I2
I2 Harmonic Currents (odd harmonics)
I2 H01
H01 Harmonic current
I2 H03
H03 Harmonic current
… ...
I2 H63
H63 Harmonic current
HRM I3
I3 Harmonic Currents (odd harmonics)
I3 H01
H01 Harmonic current
I3 H03
H03 Harmonic current
… ...
I3 H63
H63 Harmonic current
HRM I4
I4 Harmonic Currents (odd harmonics)
I4 H01
H01 Harmonic current
I4 H03
H03 Harmonic current
… ...
I4 H63
H63 Harmonic current
HRM kW
Total Harmonic kW (odd harmonics)
kW H01
H01 Harmonic kW
kW H03
H03 Harmonic kW
… ...
kW H63
H63 Harmonic kW
HRM kvar
Total Harmonic kvar (odd harmonics)
kvar H01
H01 Harmonic kvar
kvar H03
H03 Harmonic kvar
… ...
kvar H63
H63 Harmonic kvar
HRM PF
Total Harmonic PF (odd harmonics)
PF H01
H01 Harmonic PF
PF H03
H03 Harmonic PF
… ...
PF H63
H63 Harmonic PF
H1 PHASE
Fundamental Phase Values
V1 H01
V1/V12 Voltage
1
V2 H01
V2/V23 Voltage
1
