Drive PLC
Appendix
8.6 Code table
8−17
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C0096 AIF/CAN prot. AIF/CAN password protection
·
Extended password protection for bus systems when
password is activated (C0094).
·
All codes in the user menu can be accessed.
0 No password protection
1 Read protection
2 Write protection
3 Read/write protection
1 0 AIF password protection
2 0 CAN password protection
C0099 S/W version
g
Software version of operating system
C0125 Baud rate 0 LECOM baud rate
for accessory module 2102
0 9600 bit/s
1 4800 bit/s
2 2400 bit/s
3 1200 bit/s
4 19200 bit/s
C0126 MONIT CE0 3 Configuration for communication error at automation
interface (CE0)
0 TRIP
2 Warning
3 Off
C0135 Status word 2 0 Status word, access via code and FCODE_C0135
0 Not assigned
1 Not assigned
2 Not assigned
3 Run/stop 1)
4 Not assigned
5 Not assigned
6 Not assigned
7 Not assigned
8 Not assigned
9 Not assigned
10 TRIP set 2)
11 TRIP reset 3)
12 Not assigned
13 Not assigned
14 Not assigned
15 Not assigned
1) Control bit of operating unit, no effect on Drive PLC
2) If C581 < 3 (message also possible)
3) Afterwards set to FALSE by operating system
C0150 Status word 0 Status word, access via code and FCODE C0150
0 Not assigned
1 Not assigned
2 Not assigned
3 Not assigned
4 Not assigned
5 Not assigned
6 Not assigned
7 PLC stopped
8 Controller status 1
9 Controller status 2
10 Controller status 3
11 Controller status 4
12 Warning active
13 Message active
14 Not assigned
15 Not assigned
Free bits (0 ... 6, 14, 15) can be written via FCODE_C0150.
