8.6
Code table
Drive PLC
Appendix
8−34
L
DrivePLC DE 6.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C2454 CAN addr
FIF−CAN: Definition of individual PDO identifiers
1
{1}
512
1
129
FIF−CAN1_IN
2
1
FIF−CAN1_OUT
3
257
FIF−CAN2_IN
4
258
FIF−CAN2_OUT
5
385
FIF−CAN3_IN
6
386
FIF−CAN3_OUT
C2455 CAN Id
g
FIF−CAN: PDO identifiers
385
{1}
896
1
FIF−CAN1_IN
2
FIF−CAN1_OUT
3
FIF−CAN2_IN
4
FIF−CAN2_OUT
5
FIF−CAN3_IN
6
FIF−CAN3_OUT
C2456 CAN1 boot up
FIF−CAN: Time settings
1
3000
0
{1 ms}
65000 Delay time after power−on for initialisation through the
"quasi" master.
2
0
0
{1}
65000
0 = Event−controlled transmission
Task time factor for sending the FIF−CAN2_OUT process
data object.
3
0
Task time factor for sending the FIF−CAN3_OUT process
data object.
4
20
0
{1 ms}
65000 Delay time for sending the process data object.
C2457 CE monit time
FIF−CAN: Monitoring time for process data input objects
0
{1 ms}
65000
1
3000
CE11monit time
2
3000
CE12monit time
3
3000
CE13monit time
C2458 Reset node
0
FIF−CAN: Reset node
0
No function
1
FIF−CAN reset node
C2459 CAN1 state
g
FIF−CAN: Status
0
Operational
1
Pre−operational
2
Warning
3
Bus off
C2460 CAN message
g
FIF−CAN: Telegram counter
(number of telegrams)
·
For values > 65535 counting restarts with 0
0
{1 ms}
65535
1
all sent
2
all received
3
Sent to FIF−CAN1_OUT
4
Sent to FIF−CAN2_OUT
5
Sent to FIF−CAN3_OUT
6
Sent to parameter data channel 1
7
Sent to parameter data channel 2
8
Received by FIF−CAN1_IN
9
Received by FIF−CAN2_IN
10
Received by FIF−CAN3_IN
11
Received by parameter data channel 1
12
Received by parameter data channel 2
