Drive PLC
System blocks − Extension Board 3
7.2 ANALOG5_IO_EB3 (node number 15)
7−3
L
DrivePLC DE 6.0
7.2 ANALOG5_IO_EB3 (node number 15)
7.2.1 Inputs_ANALOG5 (analog input 5 of extension board 3)
This SB is the interface for analog signals via terminal AI5, A
^ of the extension board 3.
AI5
A
AIN5_nIn_a
Inputs_ANALOG5
Fig. 7−2 Inputs_ANALOG5
System variables
Variable Data type Signal type Address Display
code
Display
format
Notes
AIN5_nIn_a Integer analog %IW15.0 − − Analog input 5
Terminal assignment
Terminal X2 Use Data
AI5 Analog input 5 Level:
Resolution:
Internal resistance:
Normalisation: −10 V ... +10 V
10 bits + sign
100 k
W
±10 V º ±16384 º ±100 %
A ^ Internal ground, GND −
