8.5 System error messages
8−15
L
DrivePLC DE 6.0
Fault reset
The current fault can be reset by a TRIP−RESET e.g. via C0043:
Code LCD Possible settings Info
Lenze Selection
C0043 Trip reset 0 TRIP reset
0 TRIP−RESET (current TRIP reset)
1 Error occurred (TRIP is active)
Deleting entries in the fault memory
The entries in the fault memory can be deleted via C0167.
·
This function can only be used if there is no active fault.
Code LCD Possible settings Info
Lenze Selection
C0167 Reset failmem 0 Reset fault memory
0 No function
1 Delete all entries in history buffer
8.5.6 Error analysis via the PLC LED
Two LEDs at the front of the PLC indicate the controller status:
LED green LED red Controller status Check test
−− « Warning C0183, C0168/1
−− «« Message C0183, C0168/1
−− n Error: TRIP C0183, C0168/1
«« o PLC program not loaded C0183, C0168/1
o o PLC program loaded
n o PLC program running
« o PLC program loaded but stopped
n on o off «blinking (every second) ««blinking (every 0.5 s) −− Status without meaning
8.5.7 Fault analysis via the 9371BB keypad
Displayed status messages indicate the controller status:
Display Controller status Check test
RDY PLC ready for operation C0183, C0168/1
Fail Error indicated by TRIP, message or warning
