1.2.2 Node numbers
The system blocks of the Drive PLC carry the following node numbers:
Node number System block Notes
1 DIGITAL_IO Digital inputs/outputs
2 DIGITAL_IO_EB1 Digital inputs/outputs, internal extension module Extension board 1
3 DIGITAL_IO_EB2 Digital inputs/outputs, internal extension module Extension board 2
4 DIGITAL_IO_EB3 Digital inputs/outputs, internal extension module Extension board 3
11 ANALOG1_IO Analog inputs/outputs 1
12 ANALOG2_IO Analog input 2
13 ANALOG3_IO Analog input 3
14 ANALOG4_IO_EB3 Analog input 4, internal extension module Extension board 3
15 ANALOG5_IO_EB3 Analog input 5, internal extension module Extension board 3
21 DFIN_IO_DigitalFrequency Encoder input, internal extension module Extension board 3
31 CAN1_IO System bus (CAN) 1
32 CAN2_IO
33 CAN3_IO
34 FIF_CAN1_IO
System bus (CAN), CAN−I/O 1 FIF module
35 FIF_CAN2_IO
36 FIF_CAN3_IO
41 AIF1_IO_AutomationInterface
Automation interface
42 AIF2_IO_AutomationInterface
43 AIF3_IO_AutomationInterface
101 CAN_Management System bus (CAN) management 1
102 CAN_Synchronization System bus (CAN) synchronisation 1
111 FIF_CAN_Management System bus (CAN) management, CAN−I/O 1 FIF module
141 FCODE_FreeCodes Free codes
150 AD_Channels AD channels (24 V supply voltage)
151 SYSTEM_FLAGS System flags
161 AIF_IO_Management Automation interface management
200 DIGITAL_IO_FIF Digital inputs/outputs, Standard I/O
FIF module
201 ANALOG_IO_FIF Analog inputs/outputs, Standard I/O
FIF module
202 FIF_CAN_DIGITAL_IN Digital input, CAN−I/O
FIF module
1 SBs for system bus (CAN) are described in the System bus (CAN) for Lenze PLCs Manual.
The node number is part of an absolute SB address (see chapter 1.2.4). (
^ 1−5)
