2.7

ANALOG2_IO (node number 12)

Drive PLC

System blocks

2−22

L

DrivePLC DE 6.0

2.7

ANALOG2_IO (node number 12)

2.7.1

Inputs_ANALOG2 (analog input)

This SB forms the interface for analog signals via terminal AI2, A

^.

AI2

A

AIN2_nIn_a

Inputs_ANALOG2

C0400/2

Fig. 2−12

Inputs_ANALOG2

System variables

Variable

Data type

Signal type

Address

Display

code

Display

format

Notes

AIN2_nIn_a

Integer

analog

%IW12.0

C0400/2

dec [%]

Analog input 2

Terminal assignment

Terminal

Use

Data

AI2

Analog input 2

Level:
Resolution:
Internal resistance:
Normalisation:

−10 V ... +10 V
10 bits + sign
100 k

W

±10 V º ±16384 º ±100 %

A

^

Internal ground, GND

−
