8.6 Code table
8−31
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C2353 XCAN addrselx AIF−CAN: Source for PDO identifiers
0 Identifier assignment via C2350 + basic identifier
1 Identifier assignment via C2354/x
1 0 XCAN1_IN/OUT
2 0 XCAN2_IN/OUT
3 0 XCAN3_IN/OUT
C2354 XCAN sel.addr AIF−CAN: Definition of individual PDO identifiers
·
Value to be entered = Identifier − 384
0 {1} 1663
1 129 XCAN1_IN
2 1 XCAN1_OUT
3 257 XCAN2_IN
4 258 XCAN2_OUT
5 385 XCAN3_IN
6 386 XCAN3_OUT
C2355 XCAN Id g AIF−CAN: PDO system bus identifiers
384 {1} 2047
1 XCAN1_IN
2 XCAN1_OUT
3 XCAN2_IN
4 XCAN2_OUT
5 XCAN3_IN
6 XCAN3_OUT
C2356 CAN boot up AIF−CAN: Time settings
0 {1 ms} 65000 Delay time after power−on for initialisation through the
"quasi" master
1 0
0 {1 ms} 65000
0 = Event−controlled transmission
Cycle time for transmitting the process data object
2 0 XCAN1_OUT
3 0 XCAN2_OUT
4 0 XCAN3_OUT
5 0 XCAN Sync Tx cycle time
C2357 CExmonit time AIF−CAN: Monitoring time for process data input objects
0 {1 ms} 65000
1 3000 XCAN1_IN
2 3000 XCAN2_IN
3 3000 XCAN3_IN
4 3000 Bus off
5 3000 AIF monitoring time; can only be set if C2357/6 = 0
6 0 XCAN sync monitoring time; can only be set if C2357/5 =
0
C2359 AIF HW Set. g AIF module DIP switch settings (bit−coded)
0 {1} 65535
C2364 0 Event−controlled PDO transmission
0 Send PDOs when changing to Operational mode
1 Do not send PDOs
