Drive PLC
System blocks − FIF Standard−I/O
3.1 ANALOG_IO_FIF (node number 201)
3−3
L
DrivePLC DE 6.0
3.1.2 Outputs_ANALOG_FIF (analog output, "Standard I/O" FIF module)
This SB can be used as a monitor output. Internal signals can be given out as voltage signals via
terminal 62 of the Standard I/O FIF module and used, e.g. as display or setpoint values for following
drives.
62
AOUT1_nOut_FIFSTDIO_a
Outputs_ANALOG_FIF
C0484
7
Fig. 3−2 Outputs_ANALOG_FIF
System variables
Variable Data type Signal type Address Display
code
Display
format
Notes
AOUT1_nOut_FIFSTDIO_a Integer analog %QW201.0 C0484 dec [%] Analog output 1
Standard I/O
Function
A voltage of 10 V is given out at terminal 62 of the Standard I/O FIF module if the signal at
AOUT1_nOut_FIFSTDIO_a = 16384 = 100 %.
Electrical data of the output terminals:
Terminal Use level Data
62 Analog output 1 0 ... +10 V Resolution:
Linearity error:
Temperature error:
Load capacity: 10 bit
±0.5 %
±0.3 % (0 ... 60 °C)
max. 2 mA
7 GND1, reference potential
for analog signals − −
Tip!
Detailed information about the terminal assignment for the Standard I/O FIF module can be found
in the corresponding Mounting Instructions!
