8.6
Code table
Drive PLC
Appendix
8−26
L
DrivePLC DE 6.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C0479 DIGOUT FIF
g
Standard I/O FIF module: Digital output
0
{dec}
255
Decimal value is bit−coded:
Bit 0
DIGOUT_bOut1_FIFSTDIO_b
Bit 1
Not assigned
...
...
Bit 7
Not assigned
A1
C0481 AIN FIF
g
Standard I/O FIF module: Analog input
AIN1_nIn_FIFSTDIO_a
−199.99
{0.01 %}
199.99
C0484 AOUT FIF
g
Standard I/O FIF module: Analog output
AOUT1_nOut_FIFSTDIO_a
−199.99
{0.01 %}
199.99
C0504
PLC memory: RAM access via codes
·
More detailed information can be found in chapter
8.6.2, "RAM access via codes".
^ 8−38
C0505
C0506
C0507
C0508
C0509
C0517 User menu
User menu with up to 32 entries
·
The numbers of the desired codes are entered under
the subcodes.
·
The data is input in xxx.yy format
– xxx: Code number
– yy: Subcode for code
·
There is no check whether the entered code exists.
0.00
{0.01}
7999.00
1
372.00
C0372/0
FIF module Id
2
373.00
C0373/0
EB module Id
3
2113.00
C2113/0
PLC Prog Name
4
2108.00
C2108/0
PLC run/stop
5
0.00
Not assigned
6
400.01
C0400/1
DIS: OUT (AIN1_nIn_a)
7
400.02
C0400/2
DIS: OUT (AIN2_nIn_a)
8
400.03
C0400/3
DIS: OUT (AIN3_nIn_a)
9
434.00
C0434/0
DIS: IN (AOUT1_nOut_a)
10
443.00
C0443/0
DIGIN 8−1
11
444.00
C0444/0
DIGOUT 4−1
12
0.00
Not assigned
13
0.00
Not assigned
14
2106.00
C2106/0
In preparation
15
0.00
Not assigned
...
...
...
18
0.00
Not assigned
19
2100.00
C2100/0
Time slice
20
2102.00
C2102/0
Task switch
21
2104.00
C2104/0
PLC Autorun
22
0.00
Not assigned
23
2108.00
C2108/0
PLC run/stop
24
2110.00
C2110/0
25
0.00
Not assigned
...
...
...
31
0.00
Not assigned
32
94.00
C0094/0
Password
