8.6 Code table
8−25
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C0448 DIGOUT 10−5 g Extension board 1: Digital outputs
0 {dec} 255
Decimal value is bit−coded:
Bit 0 DIGOUT_bOut5_b
Bit 1 DIGOUT_bOut6_b
Bit 2 DIGOUT_bOut7_b
Bit 3 DIGOUT_bOut8_b
Bit 4 DIGOUT_bOut9_b
Bit 5 DIGOUT_bOut10_b
Bit 6 Not assigned
Bit 7 Not assigned
O5
O6
O7
O8
O9
O10
C0470 FCODE 8bit Freely configurable code (digital signals)
·
C0470 has the same memory address as code C0471.
0 {1} 255
1 0 C0470/1 = C0471, bit 0 ... 7
2 0 C0470/2 = C0471, bit 8 ... 15
3 0 C0470/3 = C0471, bit 16 ... 23
4 0 C0470/4 = C0471, bit 24 ... 31
C0471 FCODE 32bit 0 Freely configurable code (digital signals)
·
Variables assigned via FCODE_FreeCodes:
FCODE_bC471Bit0_b ... FCODE_bC471Bit31_b
·
C0471 has the same memory address as code C0470.
0 {1} 4294967296
C0472 FCODE analog Freely configurable code (relative analog signals)
−199.99 {0.01 %} 199.99
1 0 FCODE_bC472_1_a
... ... ...
20 0 FCODE_bC472_20_a
C0473 FCODE abs Freely configurable code (absolute analog signals)
−32767 {1} 32767
1 1 FCODE_bC473_1_a
2 1 FCODE_bC473_2_a
3 0 FCODE_bC473_3_a
... ... ...
10 0 FCODE_bC473_10_a
C0474 FCODE Lint Freely configurable code (angle/position signals)
−2147483648 {1} 2147483647
1 0 FCODE_dnC474_1_p
... ... ...
5 0 FCODE_dnC474_5_p
C0475 FCODE int Freely configurable code (speed signals)
−16000 {1 rpm} 16000
1 0 FCODE_nC475_1_v
2 0 FCODE_nC475_2_v
C0477 DIGIN FIF
g
Standard I/O FIF module: Digital inputs
0 {dec} 255
Decimal value is bit−coded:
Bit 0 DIGIN_bIn1_FIFSTDIO_b
Bit 1 DIGIN_bIn2_FIFSTDIO_b
Bit 2 DIGIN_bIn3_FIFSTDIO_b
Bit 3 DIGIN_bIn4_FIFSTDIO_b
Bit 4 DIGIN_bIn28_FIFSTDIO_b
Bit 5 Not assigned
Bit 6 Not assigned
Bit 7 Not assigned
E1
E2
E3
E4
28
