Drive plc, Appendix, 6 code table – Lenze Global Drive PLC Developer Studio User Manual
Page 112
8.6
Code table
Drive PLC
Appendix
8−32
L
DrivePLC DE 6.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C2365
1
0
0
Deactivated
1
Activated
2
Reception activated
3
Transmission activated
2nd parameter channel enabled
2
1
1st process data channel enabled
3
1
2nd process data channel enabled
4
1
3rd process data channel enabled
C2367 Sync Rx Id
128
AIF−CAN: Sync Rx identifier
·
Receive identifier for the sync telegram
0
{1}
2047
C2368 Sync Tx Id
128
AIF−CAN: Sync Tx Identifier
·
Send identifier for the sync telegram
0
{1}
2047
C2369
0
Consumer heartbeat COB−ID
0
{1}
255
C2370
0
{1}
65535
1
0
Consumer heartbeat time
2
0
Producer heartbeat time
C2371
128
Emergency object COB−ID
0
{1}
2047
C2372
0
Inhibit time emergency
0
{1}
65535
C2373 XSyncRate IN
AIF−CAN: Sync counter
1
{1}
240
1
1
XCAN1_IN
2
1
XCAN2_IN
3
1
XCAN3_IN
C2374 XSyncRate OUT
AIF−CAN: Sync counter
1
{1}
240
1
1
XCAN1_OUT
2
1
XCAN2_OUT
3
1
XCAN3_OUT
C2375 XCAN Tx mode
AIF−CAN: TX mode for XCANx_OUT
·
Selection of cycle time under C2356
0
Sync with response
1
Sync without response
2
Event−controlled (with mask)/cyclically
3
Event−controlled (with mask)
with cyclic overlay
1
0
XCAN1_OUT
2
1
XCAN2_OUT
