8.6 Code table
8−27
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C0581 MONIT EEr 3 Monitoring configuration: "ExternalFault"(FWM EEr)
The system block is integrated as of software version
V8.0.
0 TRIP
1 Message
2 Warning
3 Off
C0591 MONIT CE1 3 System bus: Monitoring configuration
CAN1_IN communication error (CE1)
0 TRIP
2 Warning
3 Off
C0592 MONIT CE2 3 System bus: Monitoring configuration
CAN2_IN communication error (CE2)
0 TRIP
2 Warning
3 Off
C0593 MONIT CE3 3 System bus: Monitoring configuration
CAN3_IN communication error (CE3)
0 TRIP
2 Warning
3 Off
C0595 MONIT CE4 3 System bus: Monitoring configuration
BusOffState" (CE4)
0 TRIP
2 Warning
3 Off
C0603 MONIT CE5 3 System bus: Monitoring configuration
Time−out when remote parameter setting activated
(C0370)
0 TRIP
2 Warning
3 Off
C0608 ovr Tx−Queue 0 System bus: Monitoring configuration
Tx buffer (send memory overflow)
0 TRIP
1 Message
2 Warning
3 Off
C0855 DIS: IN 15−0 g Automation interface (AIF): Process data input words
0000 {hex} FFFF
Hexadecimal value is bit−coded:
1 Bit 00 AIF1_bInB0_b
Bit 01 AIF1_bInB1_b
...
Bit 15
AIF1_bInB15_b
AIF1_IN: Process data input word 3
2 Bit 00 AIF1_bInB16_b
Bit 01 AIF1_bInB17_b
...
Bit 15
AIF1_bInB31_b
AIF1_IN: Process data input word 4
C0856 DIS: IN.Wx g Automation interface (AIF): Process data input words
−32768 {1 %} 32767
1 AIF1_IN: Process data input word 2 (AIF1_nInW1_a)
2 AIF1_IN: Process data input word 3 (AIF1_nInW2_a)
3 AIF1_IN: Process data input word 4 (AIF1_nInW3_a)
