4.1 FIF_CAN_DIGITAL_IN (node number 202)
Drive PLC
System blocks − FIF CAN−I/O
4−2
L
DrivePLC DE 6.0
4.1 FIF_CAN_DIGITAL_IN (node number 202)
4.1.1 FIF_CAN_Inputs_DIGITAL (digital input, "CAN−I/O" FIF module)
This SB reads the signal at terminal 28 of the CAN−I/O FIF module and conditions it.
28
DIGIN_bIn28_FIFCANIO_b
FIF_CAN_DIGITAL_IN
20
20
E1
20
E2
59
7
7
LO
HI
X3
Fig. 4−1 FIF_CAN_DIGITAL_IN
System variables
Variable Data type Signal type Address Display
code
Display
format
Notes
DIGIN_bIn28_FIFCANIO_b
Bool binary
%IX202.0.0
− − DIGIN_bIn1_FIFCANIO_b %IX202.0.1 E1
DIGIN_bIn2_FIFCANIO_b %IX202.0.2 E2
Electrical data of the input terminal
Terminal Use Data
28 freely assignable LOW level:
HIGH level:
Input resistance:
0 ... +3 V
+12 ... +30 V
(PLC level, HTL)
3.3 k
W
Tip!
Detailed information about the terminal assignment for the CAN−I/O FIF module can be found in the
corresponding Mounting Instructions!
