4 CAN−I/O FIF module
The CAN−I/O FIF module extends the Drive PLC by the following inputs and outputs:
Signal type Number SB Node number Info
Inputs Digital 1 FIF_CAN_DIGITAL_IN W FIF_CAN_Inputs_DIGITAL 202 ^ 4−2
System bus
(CAN) FIF_CAN1_IO W FIF_Inputs_CAN1 (FIF−CAN1_IN) 34 *
FIF_CAN2_IO W FIF_Inputs_CAN2 (FIF−CAN2_IN) 35
FIF_CAN3_IO W FIF_Inputs_CAN3 (FIF−CAN3_IN) 36
Outputs System bus
(CAN) FIF_CAN1_IO W FIF_Outputs_CAN1 (FIF−CAN1_OUT) 34
FIF_CAN2_IO W FIF_Outputs_CAN2 (FIF−CAN2_OUT) 35
FIF_CAN3_IO
W FIF_Outputs_CAN3
(FIF−CAN3_OUT) 36
* See "System bus (CAN) for Lenze PLCs" Manual
Tip!
Observe the installation kit for the CAN−I/O FIF module!
