8.6 Code table
Drive PLC
Appendix
8−36
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C2485 MONIT CE15 3 FIF−CAN: Monitoring configuration
Time−out" (CE15)
0 TRIP
3 Off
C2491 DIS: INx dig x g FIF−CAN: Process input words
0000 {hex} FFFF
Hexadecimal value is bit−coded:
1 Bit 00 FIF_CAN1_bInB0_b
Bit 01 FIF_CAN1_bInB1_b
...
Bit 15
FIF_CAN1_bInB15_b
FIF−CAN1_IN: Process input word 1
2 Bit 00 FIF_CAN1_bInB16_b
Bit 01 FIF_CAN1_bInB17_b
...
Bit 15
FIF_CAN1_bInB31_b
FIF−CAN1_IN: Process input word 2
3 Bit 00 FIF_CAN2_bInB0_b
Bit 01 FIF_CAN2_bInB1_b
...
Bit 15
FIF_CAN2_bInB15_b
FIF−CAN2_IN: Process input word 1
4 Bit 00 FIF_CAN2_bInB16_b
Bit 01 FIF_CAN2_bInB17_b
...
Bit 15
FIF_CAN2_bInB31_b
FIF−CAN2_IN: Process input word 2
5 Bit 00 FIF_CAN3_bInB0_b
Bit 01 FIF_CAN3_bInB1_b
...
Bit 15
FIF_CAN3_bInB15_b
FIF−CAN3_IN: Process input word 1
6 Bit 00 FIF_CAN3_bInB16_b
Bit 01 FIF_CAN3_bInB17_b
...
Bit 15
FIF_CAN3_bInB31_b
FIF−CAN3_IN: Process input word 2
C2492 DIS: INx.Wx
g
FIF−CAN: Process input words
−32768 {1 %} 32767
1 FIF_CAN1_nInW1_a
2 FIF_CAN1_nInW2_a
3 FIF_CAN1_nInW3_a
4 FIF_CAN2_nInW1_a
5 FIF_CAN2_nInW2_a
6 FIF_CAN2_nInW3_a
7 FIF_CAN2_nInW4_a
8 FIF_CAN3_nInW1_a
9 FIF_CAN3_nInW2_a
10 FIF_CAN3_nInW3_a
11 FIF_CAN3_nInW4_a
