8.6 Code table
Drive PLC
Appendix
8−16
L
DrivePLC DE 6.0
8.6 Code table
How to read the code table:
Column Abbreviation Meaning
Code C0168
1
2
…
8
Code C0168
Subcode 1 of code C0168
Subcode 2 of code C0168
…
Subcode 8 of code C0168
[C0156] Parameter value of code can only be changed when controller is inhibited.
LCD Keypad LCD
Lenze Lenze setting of the code
g
Display code (can only be displayed)
* The "Info" column contains more information.
Selection 1 {1 %} 99 Minimum value {smallest step/unit} maximum value
Info Additional information on code
Code LCD Possible settings Info
Lenze Selection
[C0002] Par load 0 Load parameter set
·
Only possible when PLC has been stopped.
·
Parameter set 1 is automatically loaded after
power−on.
0 Load Lenze setting into RAM
1 Load parameter set 1 into RAM
C0003 Par save 0 Save parameter set
·
Also possible when PLC is in operation.
0 Saving completed
1 Non−volatile saving of parameter set 1
C0004 Op display 372 Keypad operating display
·
Keypad will indicate selected code in the operating
level if no other status indications of C0183 are active.
All available codes
C0009 LECOM address 1 LECOM controller address
(bus device number for operation via interface)
·
10, 20, ..., 90 reserved for broadcast to device groups
for RS232, RS485, fibre optics.
1 {1} 99
C0011 Nmax 3000 Reference code for speed scaling
500 {1 rpm} 16000
C0043 Trip reset Current TRIP reset
0 Trip reset
1 Trip active
C0067 Act trip g Current TRIP
("0" is displayed for FAIL−QSP, warning and message.)
C0093 PLC ident
g
Controller identification
C0094 Password 0 Keypad password protection
·
Parameter password protection for the keypad.
·
When the password is activated, only user−menu codes
can be accessed.
·
For extended password protection, please see C0096.
0 {1} 9999
0 = No password protection
