8.6 Code table
Drive PLC
Appendix
8−24
L
DrivePLC DE 6.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C0429 TP delay 0 Extension board 3: DFIN_IO
Touch probe delay
·
Compensation of delay times of TP signal source at
X3/I1
−32767 {1 inc} 32767
C0431 DFIN TP EDGE 0 Extension board 3: DFIN_IO
Touch probe activation
·
For touch probe via digital input X3/I1
(C0428 = 1)
0 Activation with positive signal
1 Activation with negative signal
C0434 AOUT1 g Analog output
AOUT1_nOut_a
−199.99 {0.01 %} 199.99
C0443 DIGIN 8−1 g Digital inputs
0 {dec} 255
Decimal value is bit−coded:
Bit 0 DIGIN_bIn1_b
Bit 1 DIGIN_bIn2_b
Bit 2 DIGIN_bIn3_b
Bit 3 DIGIN_bIn4_b
Bit 4 DIGIN_bIn5_b
Bit 5 DIGIN_bIn6_b
Bit 6 DIGIN_bIn7_b
Bit 7 DIGIN_bIn8_b
I1
I2
I3
I4
I5
I6
I7
I8
C0444 DIGOUT 4−1 g Digital outputs
0 {dec} 255
Decimal value is bit−coded:
Bit 0 DIGOUT_bOut1_b
Bit 1 DIGOUT_bOut2_b
Bit 2 DIGOUT_bOut3_b
Bit 3 DIGOUT_bOut4_b
Bit 4 Not assigned
... ...
Bit 7 Not assigned
O1
O2
O3
O4
C0446 22−17 DI 16−9 g Extension board 1/2: Digital inputs
·
I15 ... I22 only with extension board 2
0 {dec} 255
Decimal value is bit−coded:
1 Bit 0 DIGIN_bIn9_b
Bit 1 DIGIN_bIn10_b
Bit 2 DIGIN_bIn11_b
Bit 3 DIGIN_bIn12_b
Bit 4 DIGIN_bIn13_b
Bit 5 DIGIN_bIn14_b
Bit 6 DIGIN_bIn15_b
Bit 7 DIGIN_bIn16_b
I9
I10
I11
I12
I13
I14
I15
I16
2 Bit 0 DIGIN_bIn17_b
Bit 1 DIGIN_bIn18_b
Bit 2 DIGIN_bIn19_b
Bit 3 DIGIN_bIn20_b
Bit 4 DIGIN_bIn21_b
Bit 5 DIGIN_bIn22_b
Bit 6 Not assigned
Bit 7 Not assigned
I17
I18
I19
I20
I21
I22
