8.6
Code table
Drive PLC
Appendix
8−22
L
DrivePLC DE 6.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C0362 Sync cycle
g
System bus: Time between two sync telegrams
1
{1 ms}
30
C0363 Sync corr
1
System bus: Sync correction increments
1
0.4
ms/ms
2
0.8
ms/ms
3
1.2
ms/ms
4
1.6
ms/ms
5
2.0
ms/ms
C0365 DIS:CAN active
g
Input signal CAN active
0
CAN not active
1
CAN active
C0366 Sync response
1
System bus: Sync response
0
No response
1
Response to sync
No response
PLC responds to a sync telegram by sending the
CAN1_OUT object.
C0367 Sync Rx Id
128
System bus: Sync Rx identifier
Receive identifier of the Sync telegram.
1
{1}
256
C0368 Sync Tx Id
128
System bus: Sync Tx identifier
Send identifier of the sync telegram.
1
{1}
256
C0369 Sync Tx time
0
System bus: CAN sync send telegram cycle
·
A sync telegram with the identifier of C0368 is sent
with the set cycle time.
0
{1}
65000
0 = off
C0370 Gateway addr.
0
System bus: Activate SDO gateway remote parameterisa-
tion
The SDO gateway cannot be used to read out codes
>C2000 or codes of the Inverter Drives 8400 and Servo
Drives 9400.
·
When selecting a setting
¹0, all code read/write acces-
ses will be redirected to the system bus device with the
corresponding node address.
·
The codes are accessed via the SDO1 parameter chan-
nel of the target device. The source or target of the
code accesses is defined in C0371.
0
{1}
63
0 = remote parameter setting deactivated
C0371 Gateway channel 1
System bus: Sync response
1
On board CAN
2
FIF CAN
·
Selection 1 (on board CAN): Parameter settings made
via AIF or FIF−CAN are transferred to the on board CAN
interface. For remote parameterisation, C0370 must be
non−zero.
·
Selection 2 (on board CAN): Parameter settings made
via AIF or FIF−CAN are transferred to the FIF CAN inter-
face. For remote parameterisation, C0370 must be
non−zero.
C0372 FIF module Id
g
FIF module HW identification
0
No module
1
Standard I/O
2
System bus (CAN)
6
Intelligent module
10
No valid identification
C0373 EB module Id
g
Extension board HW identification
0
No module
1
Standard module (extension board 1)
10
No valid identification
