2.12 DCTRL_DriveControl (node number 121)
Drive PLC
System blocks
2−34
L
DrivePLC DE 6.0
2.12.2 Outputs_DCTRL
System variables
Variable Data type Signal type Address
Display
code
Display
format
Notes
DCTRL_bTripSet_b Bool binary %QX121.0.3 − − TRIP set
DCTRL_bTripReset_b Bool binary %QX121.0.4 − − Trip reset
Codes
Code LCD Possible settings Info
Lenze Selection
C0043 Trip reset Active error TRIP reset
0 Trip reset
1 Trip active
C0135 Status word 2 0 Status word, access via code and
FCODE_C0135
0 Not assigned
1 Not assigned
2 Not assigned
3 Run/stop 1)
4 Not assigned
5 Not assigned
6 Not assigned
7 Not assigned
8 Not assigned
9 Not assigned
10 TRIP set 2)
11 TRIP reset 3)
12 Not assigned
13 Not assigned
14 Not assigned
15 Not assigned
1) Control bit of operating unit, no effect on Drive PLC
2) If C581 < 3 (message also possible)
3) Afterwards set to FALSE by operating system
Tip!
The assignment of the status word bits marked as "not assigned" depends on the AIF module used
and the set transfer profile (e.g.: DRIVECOM).
