3.2 DIGITAL_IO_FIF (node number 200)
Drive PLC
System blocks − FIF Standard−I/O
3−4
L
DrivePLC DE 6.0
3.2 DIGITAL_IO_FIF (node number 200)
3.2.1 Inputs_DIGITAL_FIF (digital inputs, "Standard I/O" FIF module)
This SB reads the signals at terminals E1 ... E4, 28 of the Standard I/O FIF module and conditions
them.
E1
E2
DIGIN_bIn1_FIFSTDIO_b
Inputs_DIGITAL_FIF
C0477
E3
E4
28
DIGIN_bIn2_FIFSTDIO_b
DIGIN_bIn3_FIFSTDIO_b
DIGIN_bIn4_FIFSTDIO_b
DIGIN_bIn28_FIFSTDIO_b
Fig. 3−3 Inputs_DIGITAL_FIF
System variables
Variable Data type Signal type Address Display
code
Display
format
Notes
DIGIN_bIn28_FIFSTDIO_b
Bool binary
%IX200.0.0 C0477 − bit2
bin
DIGIN_bIn1_FIFSTDIO_b %IX200.0.1 C0477 − bit3
DIGIN_bIn2_FIFSTDIO_b %IX200.0.2 C0477 − bit4
DIGIN_bIn3_FIFSTDIO_b %IX200.0.3 C0477 − bit5
DIGIN_bIn4_FIFSTDIO_b %IX200.0.4 C0477 − bit1
Electrical data of the input terminals:
Terminal Use Data
E1
freely assignable
LOW level:
HIGH level:
Input resistance:
0 ... +3 V
+12 ... +30 V
(PLC level, HTL)
3.3 k
W
E2
E3
E4
28
Tip!
Detailed information about the terminal assignment for the Standard I/O FIF module can be found
in the corresponding Mounting Instructions!
