Drive plc, Appendix, 6 code table – Lenze Global Drive PLC Developer Studio User Manual
Page 109
Drive PLC
Appendix
8.6
Code table
8−29
L
DrivePLC DE 6.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C0868 DIS: OUTx.Wx
g
System bus: Process data output words
−32768
{1 %}
32767
1
CAN1_nOutW1_a
2
CAN1_nOutW2_a
3
CAN1_nOutW3_a
4
CAN2_nOutW1_a
5
CAN2_nOutW2_a
6
CAN2_nOutW3_a
7
CAN2_nOutW4_a
8
CAN3_nOutW1_a
9
CAN3_nOutW2_a
10
CAN3_nOutW3_a
11
CAN3_nOutW4_a
C1120 Sync mode
0
System bus: Sync source
0
Off
1
Synchronisation via system bus (CAN)
2
Synchronisation via terminal X3/I1
C1121 Sync cycle
2
System bus: Synchronisation cycle
·
Definition of the cycle time of the sync telegram/signal.
·
Parameterisation is only required for the slave!
1
{1 ms}
13
C1122 Sync phase
0
System bus: Synchronisation phase
·
Phase shift between the sync telegram/signal and the
start of the internal control program.
0
{0.001 ms}
6.5
C1123 Sync window
0
System bus: Synchronisation window
·
If the sync telegram/signal sent from the master is
within the "time window",
CAN_bSyncInsideWindow_b = TRUE.
0
{0.001 ms}
6.5
C1810 S/W Id keypad
g
Keypad identification
C1811 S/W date keypad
g
Keypad creation date
C2100 Time slice
13
Time slice for task switch between system task and cyclic
task (PLC_PRG)
6
{1 ms}
26
C2102 Task switch
0
Configuration of task switch process
Activation after:
0
Time slice
1
Time slice + end PLC_PRG
2
Time slice + end PLC_PRG + end system task
C2104 PLC Autorun
0
Automatic start of the PLC program after power switch−on
0
No auto start
1
Auto start after mains connection
C2106 Downl.protect
0
Write protection for the PLC program
0
New download possible
1
No new download possible
C2107 PwDownlProt.
0
Password for download write protection (C2106)
0
{1}
4294967295
C2108 PLC run/stop
0
PLC program
0
No function
1
PLC run
2
PLC stop
3
PLC reset
start
stop
reset
C2110
Internal code
