94 User Manual
7.1.5 Serial Ports
Change parameters: Changes the parameters of the serial interface. This menu
allows to select the Port (Signal Source), the Baud Rate between 300 or 115200,
the Data Bits (Word Length) between 7 or 8, the Parity between even, odd or
none, the Stop Bits between 1 or 2.
Input Data Display: Allows the chart plotter to act as a computer terminal and
display the incoming data exactly as it is received. If the data displayed on the
screen is unrecognizable, you may have selected the wrong input parameters for
your particular receiver. Check your receiver manual to be sure that you have
selected the proper interface format. If the screen is blank, the connection may
be interrupted, and no data is being received. Use [PAGE] to stop (or continue
after pause) data displaying, [ENTER] to show data in hex or ASCII mode (nor-
mal or small) and [CLEAR] to exit.
SW701e/SW701i/SW701ce/SW701ci/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3 :
7.1.6 External Alarm
To check the External Alarm signal.
