71 User Manual
Pressing [ENTER] it is possible, by selecting "DELETE" deletes the DSC icon from
the DSC Log page, otherwise by selecting "DSC LOG" the DSC Log page is shown.
3.10 FISH FINDER
The chart plotter combined with the sonar performance of the Fish Finder is one
of the most advanced marine navigation system available.
To select the Fish Finder menu, first select one of the pages related to the Fish
Finder:
[PAGE] + "Fish Finder" + [ENTER] + select the desired page + [ENTER]
MARLIN:
[DATA] + "Fish Finder" + [ENTER] + select the desired page + [ENTER]
EXPLORER 3 :
[MENU] + "Fish Finder" + [ENTER] + select the desired page + [ENTER]
Once the Fish Finder page is selected, access the Fish Finder menu by pressing:
[MENU]
For more information see the specific User Manual (or Chapter 5).
NOTE The Fish Finder display page is available only if the Fish Finder is connected/
internal and turned On.
SW701e/SW701i/SW701ce/SW701ci/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3 :
3.11 RADAR
The Radar consists of a scanner unit which illuminates targets with microwave
energy and then collects the echoes from those targets. The scanner unit includes
the Radar antenna, transmitter, receiver and necessary electronics. The scanner
unit is connected to a chart plotter equipped with software capable of displaying
the Radar functions.
To select the Radar menu, first select one of the pages related to the Radar:
[PAGE] + "Radar" + [ENTER] + select the desired page + [ENTER]
MARLIN:
[DATA] + "Radar" + [ENTER] + select the desired page + [ENTER]
EXPLORER 3 :
[MENU] + "Radar" + [ENTER] + select the desired page + [ENTER]
Once the Radar page is selected, access the Radar menu by pressing:
[MENU]
For more information see the specific User Manual.
NOTE The Radar display page is available only if the Radar is connected and powered
On.
3.12 SYSTEM INFORMATION
To see details about the software and cartography data installed.
[MENU] + "About..." + [ENTER]
Opens the System Information page.
