110 User Manual
151
mm [
5
.9
”]
154mm [6.1”]
162mm [6.4”]
6
0mm [
2
.4
”]
73mm [2.9”]
Flush mount installation
EXTERNAL WIRING
QUICK DISCONNECT BRACKET CABLE
DESCRIPTION WIRE COLOR
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE
POWER SUPPLY GND
POWER SUPPLY+
NMEA0183/C-COM
SIGNAL RETURN
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
SIGNAL RETURN
GND/COMMON
POWER +10-35Vdc
INPUT1+
SIGNAL RETURN-
OUTPUT1+
NC
NC
INPUT3+ (*)
OUTPUT3+ (*)
SIGNAL RETURN-
FUNCTION
(*) Available on Chart Plotter
with External GPS
External Wiring
TYPICAL CONNECTIONS
GPS Connection on Port 3 for SW501ce
