132 User Manual
♦
Route Data Report and User Points (Marks/Events/Waypoints) List pages
♦
Display vessel's position, direction and Track
♦
Alarms Handling (Auto Off, Arrival Alarm, XTE Alarm, Anchor Alarm,
Depth Alarm, HDOP Alarm, Heading Alarm, Timer Alarm, Grounding
Alarm, External Alarm)
♦
Man OverBoard (MOB) to navigate back to a missing person or object
♦
C-Link and C-Weather Service
♦
EBL-VRM and A-B functions
♦
Simulation Mode with cursor control
♦
Video Input option
♦
Video Output option
NOTE 1 If Fish Finder/Radar/Video Camera connected.
TECHNICAL SPECIFICATIONS
♦
Power consumption : 1.6A @10V
♦
Power supply : 10 - 35 Volt dc, 16 Watt
♦
Interface : NMEA0183
♦
Autopilot Interface : NMEA-0180, NMEA-0180/CDX, NMEA-
0183
♦
Video Input : PAL or NTSC video signals automati-
cally selected
♦
Video Output : VGA compatible (with adapter cable)
♦
Display : LCD 12.1" TFT Color, polarized
♦
Display Resolution : 800 x 600 pixels
♦
MEDIA : C-Card
♦
Cartography : C-MAP B
Y
J
EPPESEN
DATA MEDIA
♦
Auxiliary Memory : SD-Card 16 MB or more
♦
Operating temperature range : 32/131 °F (0/+55 °C)
♦
Memory : Non volatile with battery back-up
♦
Keyboard : Silicon rubber, backlight
♦
Weight : 6,2 Kg
When the package containing the chart plotter is opened for the first time after
purchase, please make sure that the following contents are present (if any item is
missing, please contact your local dealer):
♦
Power supply and I/O 8 pins cable 1,5 mt./5.9 feet; cable code
CBC0FS0804
♦
Desktop brackets kit
♦
Two I/O 6 pins cables 1 mt./3.9"; cable code CBC0FS0603
♦
Fuse 2 Amp. + fuseholder (2pcs)
♦
External packaging
♦
User Manual
INSERTING/REMOVING PROCEDURE
Inserting the MEDIA
Hold the MEDIA by the short inclined side so that you can see the C-MAP B
Y
J
EPPESEN
label. Gently push the MEDIA into one of the two slots (1); push the
MEDIA in as far as it will go, then move it to the right (2) to hold fixed into the slot
(3).
