[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Input" + [ENTER]. Then choose your preferred setting among the
NMEA available settings NMEA 1200-N81-N, NMEA 4800-N81-N, NMEA 4800-
N82-N, NMEA 9600-N81-N, NMEA 38400-N81-N and press [ENTER] to confirm.
Where:
n = 1/2/3 for SW501e/SW501i
n = 1/3 for SW501ce/SW501ci
n = 1/2/3/4/5 for SW701e/SW701i/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3
n = 1/3/4/5 for SW701ce/SW701ci
C-COM GSM Plus Connection
To connect the modem C-COM to the chart plotter follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port 1 Input" + [ENTER] + "C-COM" + [ENTER]
The modem C-COM can be connected also to the Port 2 (except for SW501ce/
SW501ci/SW701ce/SW701ci), Port 3 and Port 4/5 (except for SW501e/
SW501i/SW501ce/SW501ci), in this case select the format on the used port.
NOTE The connection is valid for the C-COM IR and C-COM RS232 too.
Output Sentences
The chart plotter allows customizing the NMEA-0183 sentence transmitted on
each port. Each port can transmit a different set of sentences among: GLL, VTG,
BOD, XTE, BWC, RMA, RMB, RMC, APB, WCV, GGA, HSC, HDG, MWV:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Output Sentences" + [ENTER]
Where:
n = 1/2/3 for SW501e/SW501i
n = 1/3 for SW501ce/SW501ci
n = 1/2/3/4/5 for SW701e/SW701i/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3
n = 1/3/4/5 for SW701ce/SW701ci
NMEA-0183 Output Talker ID
The Talker Id is the 2 characters following the “$” char (Start of sentence) in a
NMEA-0183 sentence that identifies the type of instrument that sends the string.
The chart plotter allows selecting one of the following Talker identifier: II (Inte-
grated Instrument); GP (GPS); EC (Electronic Chart System-ECS); RA (Radar
and/or Radar Plotting); SD (Sounder Depth). The selected Talker ID is applied to
all sentences sent by the chart plotter from all Ports.
To select the Talker ID follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"NMEA-0183 Output Talker ID" + [ENTER] + "II/GP/EC/RA/SD" + [ENTER]
SW701e/SW701i/SW701ce/SW701ci/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3 :
External Signal
Sets the External Output:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"External Signal" + [ENTER]
Then choose your preferred setting among External Alarm (when activated, this
pin goes to GND level. It is used to command an external buzzer), External Power
(it is command switch for the Radar. It must be used in conjunction with the Radar
Junction box device) and Off.
