Removing the MEDIA
Open the door, press in on the MEDIA and remove the MEDIA out of the slot.
CHART PLOTTER DIMENSIONS
107mm [4.2”]
147mm [5.8”]
193
mm [7.
6
”]
14
7mm [
5
.8
”]
77mm [3.1”]
1
0
3
mm
[4
.1
]
129
mm
[5
.1
”]
18
0mm [7.
1
”]
180mm [7.1”]
PROTECTIVE COVER
INSTALLATION AND REMOVING
45
mm [
1
.8
"]
74mm [2.9"]
Bracket installation
