122 User Manual
INSTALLATION AND REMOVING
45
mm [
1
.8
"]
74mm [2.9"]
Bracket Installation
5mm [0.2”]
260mm [10.2”]
1
00mm [
3
.9
”]
250mm [9.8”]
158
mm [
6
.2
”]
Flush Installation
EXTERNAL WIRING
GND COMMON
POWER OUTPUT+ (10-35 Vdc)
INPUT 4+
GND
OUTPUT 5+
OUTPUT 4+
INPUT 5+
EXT. ALARM SIGNAL (to GND when ON) BLACK
RED
WHITE
GREEN
GRAY
YELLOW
BROWN
BLUE
PIN
1
2
3
4
5
6
7
8
WIRE COLOR FUNCTION
AUX-IN I/O CABLE
1
2
3
CAM CONNECTORS
PIN-OUT
(ON UNIT)
1=GND COMMON
2=POWER+ (10-35Vdc)
3=SIGNAL
VIDEO INPUT
PIN
1
2
3
4
5
6
7
8
FUNCTION
TRANSDUCER Connector
DEPTH +
GND
TEMP1 +
POWER SUPPLY +5Vdc, 1A max
SENSE +
DEPTH SHIELD
DEPTH -
SPEED +
QUICK DISCONNECT BRACKET CABLE
DESCRIPTION WIRE COLOR
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE POWER SUPPLY GND
POWER SUPPLY+
NMEA0183/C-COM
SIGNAL RETURN
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
SIGNAL RETURN
GND/COMMON
POWER +10-35Vdc
INPUT1+
SIGNAL RETURN-
OUTPUT1+
NC
NC
INPUT3+ (*)
OUTPUT3+ (*)
SIGNAL RETURN-
FUNCTION
(*) Available on Chart Plotter with External GPS
External Connection
