EXTERNAL WIRING
PIN
POWER OUTPUT+ (10-35 Vdc)
OUTPUT 3+
INPUT 3+
GND/SIGNAL RETURN
1
2
3
4
5
6
RED
GREEN
BROWN
NC
NC
BLACK/YELLOW/SHIELD
WIRE COLOR FUNCTION
SMART
GPS
SENSOR
1 GND
2 VCC
3 R
4 G
5 B
6 HSYNC
7 VSYNC
8 N.C.
9 BRIGHT. CONTROL
PIN FUNCTION
BLACK
RED
WHITE
GREEN
GRAY
YELLOW
BROWN
BLUE
PIN
1
2
3
4
5
6
7
8
WIRE COLOR FUNCTION
GND/COMMON
POWER INPUT+ (10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 2+
OUTPUT 1+
INPUT 2+
EXTERNAL ALARM OUTPUT+
GND/COMMON
POWER OUTPUT+
INPUT 4+
COMMON
OUTPUT 5+
OUTPUT 4+
INPUT 5+
EXTERNAL ALARM OUTPUT+
(10-35 Vdc)
BLACK
RED
WHITE
GREEN
GRAY
YELLOW
BROWN
BLUE
PIN
1
2
3
4
5
6
7
8
WIRE COLOR FUNCTION
USB Port
Mini B
AUX-IN I/O CONNECTOR/CABLE POWER & I/O CONNECTOR/CABLE
GPS CONNECTOR/CABLE
VIDEO OUTPUT
CONNECTOR
1
2
3
CAM CONNECTORS
PIN-OUT (ON UNIT)
GND/COMMON
PWR + (10-35Vdc)
SIGNAL +
VIDEO INPUT
CONNECTOR
PIN
1
2
3
FUNCTION
TYPICAL CONNECTIONS
GPS Connection
SMART GPS
SENSOR
GPS SENSOR CABLE GPS SENSOR CABLE
POWER OUTPUT+ (10-35 Vdc)
GPS RX+
GPS TX+
GND COMMON
RED
GREEN
BROWN
BLACK/YELLOW/SHIELD
PIN
1
2
3
6
GPS
ANTENNA
1
2
3 4
5
6 WIRE COLOR FUNCTION
GPS on Port 3
Autopilot Connection
POWER & I/O
POWER SUPPLY
1
POWER & I/O CABLE POWER & I/O CABLE
PWR-/GND/COMMON
POWER INPUT+ (10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 1+
BLACK
RED
WHITE
GREEN
YELLOW
PIN
1
2
3
4
6
WIRE COLOR FUNCTION
- +
AUTOPILOT
COMMON
RX+
Autopilot on Port 1
