61 User Manual
the window is placed.
Radar/FF/Chart/Video : Shows the image from the video camera on a rectangular window, in the left top
corner, with Radar, Fish Finder and Chart.
3.6 ADVANCED OPTIONS MENU
[MENU] + "Advanced Options" + [ENTER]
The Advanced Options are arranged in sub-menus.
3.6.1 Input/Output menu
WARNING
After every software upgrade the RAM is cleared and the chart plotter re starts
with the usual default settings. Please go to the Input/output menu and set
the proper input format once again.
SW501e/SW501ce/SW701e/SW701ce/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3 :
GPS Connection
Connect the GPS to the GPS Port (serial Port 3). To choose your preferred setting
follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port 3 Input" + [ENTER] + "NMEA-4800-N81-N" + [ENTER]
GPS Setup Menu
To set your preferred configuration for the connected GPS.
Internal GPS 1 : Enables or disables the Internal GPS.
Restart GPS : Restarts all GPS processes. Once executed, the message "Done" is shown.
Diff. Corr. Source : Sets what kind of Differential Correction will be used by the GPS between WAAS and RTCM
(beacon correction).
Navigation Speed : Sets the Navigation Speed among Low Speed, Medium Speed and High Speed.
NOTE 1 A
VAILABLE
F
OR SW501i/SW501ci/SW701i/SW701ci.
SW501ce/SW501ci/SW701ce/SW701ci:
Fish Finder Transmission
The internal Fish Finder is connected directly to the Port 2. To switch the internal
Fish Finder transmission On/Off follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"FF Transmission" + [ENTER] + "On"/"Off" + [ENTER]
Autopilot Connection
Connect the Autopilot to the serial Port n:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Output" + [ENTER]. Then choose your preferred setting among the
NMEA available settings NMEA 0183 4800-N81-N, NMEA 0180, NMEA 0180/
CDX) and press [ENTER] to confirm.
Where:
n = 1/2/3 for SW501e/SW501i
n = 1/3 for SW501ce/SW501ci
n = 1/2/3/4/5 for SW701e/SW701i/SW1101/SEAWAVE 3 /MARLIN/
EXPLORER 3
n = 1/3/4/5 for SW701ce/SW701ci
External NMEA Connection
Connect the External NMEA to the serial Port n:
