AT-WA7500 User’s Guide
79
Example 2
This example shows how to use Ethernet filters to discard all DIX IP
multicast frames except those from selected devices. Three entries have
a value ID of 3 to demonstrate how to enter a list. All entries with the
same value ID belong to the same list. For this example, set these filter
values.
Table 13 Example 2 - Filter Values
Value ID Value Description
1 08 00 Check for a DIX IP frame.
2 01 Check for a multicast frame.
3 00 c0 b2 00 00 01
00 c0 b2 00 00 02
00 c0 b2 00 00 03
Check for these specific MAC
device addresses.
