1 - Getting Started
26
Example - Configuring an 802.11a WAP With Roaming
End Devices
In this example, there is one 802.11a radio in the access point and there is
one 802.11a radio in the WAP. Wireless end devices can roam between the
WAP and the access point.
Table 5 Configuring an 802.11a Access Point and WAP Parameters
You need to configure the wireless end devices to have the same SSID,
LAN ID, and frequency as the WAP radio. You do not need to configure
any secondary LAN settings because the WAP is not connected to a
secondary LAN.
Allied Telesyn recommends that you always implement some type of
security.
Screen Parameter Access Point
IEEE 802.11a WAP IEEE
802.11a
IEEE 802.11a
Radio Node Type Master Master
SSID ATILAN ATILAN
Spanning Tree
Settings LAN ID 11 11
Root Priority 5 0
Ethernet
Bridging
Enabled Checked Checked
Secondary LAN
Bridge Priority 0 0
Host
Ethernet
WAP
Access
point
