14.3 Electrical/video
Input voltage:
- 230Vac, 50/60Hz,
- 24Vac, 50/60Hz
- 120Vac, 50/60Hz
Current consumption:
- 230Vac, 0.4°
- 24Vac, 4°
- 120Vac, 0.8°
Power consumption:
- 40W with pan-and-tilt stopped and heating switched
off
- 60W in motion, with heating switched off
- 125W peak at start-up, with heating switched on
Dimensions of input cables: AWG 16 (24Vac) -18
(120/230Vac)
Dimensions of signal cables: AWG 20-26
Video lines: coaxial cable (1Vpp, 75Ohm)
Functions: Autopan, Preset, Patrol, Tour (max 3), Autoflip
Maximum number of presets:
- AMERICAN DYNAMICS protocol: 95*
- ERNITEC protocol: 250
- PANASONIC protocol: 250
- PELCO D protocol: 99*
- VIDEOTEC MACRO protocol: 250
- *250 from OSD (On Screen Display) only
16-characters string for zone and preset titling
I/O alarm card (option):
- 6 alarm inputs
- 2 relais outputs (2A 30Vac/60Vdc max)
14 Technical specifications
h The installation is type TNV-1, do not
connect it to SELV circuits.
h In order to reduce the risk of fire, only use
cable sizes greater than or equal to 26AWG.
14.1 General
Constructed from aluminium and tecnopolymer
Epoxypolyester powder painting, RAL9002 colour
Germanium glass window for thermal camera
Easy installation thanks to the self-centring connector
Zero backlash
Dynamic positioning control system
14.2 Mechanical
2 cable glands M16 and 2 cable glands M12
Horizontal continuous rotation
Vertical rotation -90° to +90°
Variable pan speed: from 0.1° up to 200°/s
Variable tilt speed: from 0.1° up to 200°/s
Preset accuracy: 0.05°
