Videotec ULISSE COMPACT THERMAL - Manual (Page 25)

EN - English - I
nstruc
tions manual
23
8.2 Checks list
While it is switching on, the device displays a list of
the checks it has to carry out before starting normal
operation.
STARTUP
Reading Parameters...OK
Zero axis............OK
Camera...........36x.OK
Temperature probe....OK
IR Spotlight.........--
Wiper................--
Optional Board.......--
Fig. 32
h If one of the checks fails (ERR), seek
assistance. The message “- -“ means that the
pan & tilt is not fitted with the described
option.
8 Switching on
Systems in the ULISSE COMPACT THERMAL line are
switched on by simply connecting the power supply,
and switched off by disconnecting the power.
j The automatic pre-heating (de-ice) process
could be started whenever the device is
switched on and the air temperature is
below 0°C. This process is used to ensure
that the device works properly even at
low temperatures. The duration ranges
between 60 and 120 minutes, depending
on conditions.
8.1 Before powering the device
g Make sure that the ULISSE COMPACT
THERMAL system and other components
of the installation are closed so that it is
impossible to come into contact with live
parts.
i Do not stay in the vicinity of the device
when it is powered. Always disconnect the
power supply before working on the device.
h Make sure that all parts are fastened down
firmly and safely.
The first time the device is switched on we
recommend making sure it is configured correctly.
To do this, disconnect the power supply, remove the
dip-switch protection window and set the Display
Configuration dip-switch rocker (DIP1, SW1) to ON.
Power the device and after a few seconds it will be
possible to check the settings on the screen.
After completing the check, switch off the device
and re-toggle the Display Configuration dip-switch
rocker (DIP1, SW1).
Close the window and re-connect the power supply.
