Page 12: 1 washer

EN - English - I
nstruc
tions manual
10
5 Versions
5.2.1 Washer
If the pan & tilt is fitted with a wiper, it can also have
an external pump supplying water to clean the glass.
As shown in the picture, the spray to clean the glass is
outside the pan & tilt.
Fig. 01
Once the command has been sent ("10.9 Enabling the
Washer (Washer)", page 45) the pan & tilt positions
itself with the glass facing the spray and the pump
and wiper are activated for a set period of time; at
the end of the operation ULISSE COMPACT THERMAL
returns to its initial position.
For models with Washer complete with level sensor,
ULISSE COMPACT THERMAL can also display a video
message when the level of the liquid inside the tank
is too low (only if using a high prevalence pump of
the UPTWAS series).
j
For further details on configuring and using
the Washer, refer to "9.6.7 Washer Menu",
page 38.
ULISSE COMPACT THERMAL is also available with the
only thermal camera. Supplied in 24, 230 or 120Vac
and in PAL or NTSC mode.
Besides the OSD configuration, the system is
equipped with an RS485/RS422 interface for
complete system control and for the updating in
remote mode of the latest firmware version.
This solution is particularly suited for round-the-clock
video surveillance in a wide range of high security
environments such as perimeter protection, airports,
coastlines, prisons and harbours.
4.2 Product markings
ULISSE COMPACT THERMAL pan & tilt devices
have a label complying with CE markings.
The label on the body shows:
• Model identification code (Extended 3/9 bar code)
• Power supply voltage (Volt)
• Frequency (Hertz)
• Absorbed current (Amps)
• IP weatherproof standard
• Serial number
4.2.1 Checking the markings
Before proceeding further with installation, make
sure the material supplied corresponds to the order
specification by examining the marking labels.
Never, under any circumstances, make any changes
or connections that are not described in this
handbook: the use of inappropriate appliances may
expose personnel and the system to serious safety
hazards.
