3PAR InForm Management Console 4.1.0 User’s Guide
452 320-200231 Rev A
Manufacturer The manufacturer of the drive cage.
Model/Part Number The model and/or part number of the drive cage.
Serial Number The drive cage serial number.
Firmware Version The drive cage firmware version.
Cage Type The type of drive cage (DC2, DC3, or DC4)
Cage Position The position (0 or 1) of the drive cage in the drive chassis.
See also:
Manager Pane
Management Tree
Management Window
Viewing the Cage Subsystems Tab
Viewing the Cage Subsystems Interface
Cards Tab
The Cage Subsystems Interface Cards tab displays information about the system's
interface cards.
To access the Cage Subsystems Interface Cards tab, click the Interface Cards tab
after accessing the Cage Subsystem tab .
