Network Setup for the SNC 5100
87
6-00020-02
SNC 5100
Step 1.
If you did not replace the SNC 5100, go to Step 3.
Step 2.
Obtain the SNC 5100’s Ethernet network parameters.
Configure the Ethernet Port Host Name, Address, Routes, Enable
Ethernet.
For more information, see
"Network Setup for the SNC 5100"
.
Step 3.
Attach the Ethernet loop back plug to the Ethernet port.
Step 4.
From the service terminal, enter the
elTest
command.
For more information, see the
Step 5.
If the test passes, go to Step 6.
If the test does not pass, go to See “Start MAP” on page 42.
Step 6.
Remove the Ethernet loop back plug.
Step 7.
Proceed to
.
Network Setup for the SNC 5100
The SNC 5100 must be connected to a 10/100-base-T Ethernet network for use
with the ADIC Management Console software.
For more information, see the ADIC Management Console User Guide.
An RJ-45 connector is located on the rear panel of the SNC 5100 for
connection to the Ethernet. See Figure 8.
You will need to connect a terminal or terminal emulator to the Service Port of
the SNC 5100 in order to configure the IP address.
