Final Diagnostic Tests
85
6-00020-02
SNC 5100
Step 7.
From the Service Terminal, enter the
showBox
command.
For more information, see the
Step 8.
Verify that the SNC 5100 accurately displays the channel
information.
If the
showBox
display is accurate, go to step 9.
If not, go to “Start MAP” on page 42.
Step 9.
Proceed to
Fibre Channel Tests
For further information about the procedures and commands used in this
section, see “Connecting to the Service Port” on page 95 and “Diagnostic
Command Reference” on page 187.
Test Fibre Channel Port 1
Step 1.
Attach the Fibre Channel loop back plug to the GBIC in FC 1.
Step 2.
From the service terminal, enter the
fcSlotTest 1
command.
For more information, see the
Step 3.
If the test passes, remove the loop back plug and go to
If the test does not pass, go to “Start MAP” on page 42.
Test Fibre Channel Port 2
Step 1.
Attach the Fibre Channel loop back plug to the GBIC in FC 2.
Step 2.
From the service terminal, enter the
fcSlotTest 2
command.
For more information, see the
