SNC 5100
194 Diagnostic Commands
6-00020-02
The example below shows the display for a test on SCSI channels 1 and 2.
diagmode > scsiChannelTest (3,4)
SCSI-3 -> SCSI-4 [##########] 10 iterations PASSED
SCSI-4 -> SCSI-3 [##########] 10 iterations PASSED
value = 0 = 0x0
diagmode > scsiChannelTest (1,2)
SCSI-1 -> SCSI-2 [##########] 10 iterations PASSED
SCSI-2 -> SCSI-1 [##########] 10 iterations PASSED
value = 0 = 0x0
The following output is an example of a SCSI port test that was not successful.
If your test was not succesful, return to the MAP that sent you here.
Unsuccessful SCSI Test (cable not plugged in):
diagmode > scsiChannelTest (1,2)
SCSI Initiator Error(s) - STO iUnk
SCSI Initiator Error(s) - STO iUnk
SCSI-1 -> SCSI-2 [SCSI Initiator Error(s) - STO iUnk
ERROR, i = 1 ] 1 iterations FAILURE
SCSI-2 -> SCSI-1 [SCSI Initiator Error(s) - STO iUnk
ERROR, i = 1 ] 1 iterations FAILURE
value = -1 = 0xffffffff = pNullDmaDesc + 0xfe4ea9f7
showBox
The showBox command displays the components present in the SNC 5100
using characters to form a picture of the unit, as viewed from the rear.
