showBox also lists the cabling requirements for each slot:
SN60023 > showBox
Back _________________________________________
/ /|
/ / |
/ / |
/ / |
/========================================/ |
| FC1 FC2 | |
| [SW-2] [SW-2] | /
| | /
| [LVDT] [LVDT] [LVDT] [LVDT] | /
| SCSI1 SCSI2 SCSI3 SCSI4 | /
|________________________________________|/ Front
LVDT = SCSI Low Voltage Differential - Terminated
SW-2 = Short Wave - Two GB
value = 0 = 0x0
SN60023 >
supportDump
The supportDump command outputs the result of a number of Service Port
commands in a standard way and in a specific order. The resulting file is used
for troubleshooting. The individual commands called by
supportDump are:
envShow
version
showBox
sysVpdShowAll
sysConfigShow
licenseShow
sfmShow
hostTypeShow
targets
scsiShow
fcShow 2
fcShowDevs
mapShowDevs
mapShowDatabase
showScsiAssign
fctShowChan 1
fctShowChan 2
cleShowAll
loggerDumpCurrent
