9.4 Sequence Edit Area

9-5

9.4 Sequence

Edit

Area

The sequence edit area consists of the following three areas.

<1> Common parameters setting area
<2> Sequence execution parameters setting area
<3> Branch step setting area

When “SEQ” is started, the previously set values are shown. If the software is used for the first
time or a sequence is newly created, the initial set values are shown. (For the initial set values,

see “11.8 List of Initial Setting Values”.

)

The edit area when the SEQ is started for the first time is shown in Figure 9-2.
The displayed parameters in the sequence execution parameters setting area vary depending on
the operation mode of the APS-1102 Programmable AC/DC Power Source.

<1>

<2>

<3>

Figure 9-2 Sequence Edit Area
