APS-1102 Control Software User Manual
4-4
4.2 Menu Organization
The menu organization of the “RMT Remote Control Software” is shown below.
File (F)
Memory
Status
Tool (T)
Help (H)
Logging
Open(O)* Ctrl+O
Save(S) Ctrl+S
Save As(A)
Exit(X)
Store
Recall
Reset
Monitor
Clear
Set up(S)
About(A)
Logging
Saves data in the current device setting file.
Opens the device setting file.
Saves data in the new device setting file.
Exits this software.
Displays the "Store Memory" dialog box.
Initializes the device to the factory settings.
Displays the "Recall Memory" dialog box.
Sets the start or termination of status monitor.
Clears the status display.
Displays the logging screen.
Displays the "System Setup" dialog box.
Displays the "Version Information" dialog box.
4.3 Start
For how to start the “RMT Remote Control Software”, see “3.2 Starting the
Subsoftware”.
The following message appears when the software is started for the first time or when the device
previously set is not connected.
Figure 4-4 Message Displayed at Startup
After starting the software, connect the device and make system settings.
See “4.9 System Setup”.
If the above operations are not performed, the device remains in the “offline” status.
