5.2 Menu Organization
5-3
5.1.2 Toolbar
The toolbar on the logging screen is detailed below.
Start button Stop button
Figure 5-2 Toolbar on Logging Screen
5.1.3 Status bar
The status bar on the logging screen is detailed below.
Offline or online
Mo del name o f connecte d d evice
Loggi ng start time
Figure 5-3 Status Bar on Logging Screen
Mode indicator
The mode indicator displays “ON Line” or “OFF Line”.
See “1.4 Online/Offline”.
Connected device name
Displays the connected device name. No data is displayed here in the offline status.
Logging start time
Displays the time when logging was started. No data is displayed here in the offline status.
5.2 Menu Organization
Logging
Setting(S)
Start(S)
Stop(E)
Clear
Logging Condition
Starts logging.
Clears data in the data display area.
Stops logging.
Displays the "Logging Conditions" dialog box.
